This machine tool is widely applied to the cutting operations of various spare parts, including end face, conical face, excircle, internal hole, metric thread, English standard thread, module thread, diametrical pitch thread, etc. In addition, it is applicable to the technologies such as drilling, hole-reaming, jacketing, boring, groove-cutting, etc. Hard alloy tools may be utilized to cut the screw threads and machine various ferrous metals and nonferrous metals. The size precision of spare parts machined via this machine tool can be IT8 and the surface coarseness may be 6.3μm.
4 jaw chuck; 3 jaw chuck ;steady rest; follow rest; dead center; reduction sleeve; working lamp; coolant system; tools; foundation bolt; level blocks; maintenance kits; english manual;
Note: less than 2000mm (including 2000mm) lathe steady rest and follow rest are optional.
CE standard including chuck guard, turret guard, big electric box; SINO DRO for 2 axis or 3 axis;
Lead screw cover; Chasing dial; Live center; Face plate; Foot brake;
|Swing over bed||mm||630||830||930|
|Swing in gap||mm||890||1090||1190|
|Swing over cross slide||mm||350||550||650|
|Distance between centers||mm||1000,1500,2000,3000,4500,6000|
|Length in gap from face plate||mm||300|
|Spindle nose||C11or D11|
|Spindle bore||mm||105,130 (optional)|
|Cross slide travel||mm||480|
|Top rest travel||mm||225|
|Rapid traverse||mm/min||Z:3200, X:1870|
|Diametral pitch threads||Lpi/kinds||60—0.5/47|
|Main motor power||kw||11|
CNC pipe thread lathe is a special machine tool for pipe thread turning machining. Its feature is that the spindle bore is relatively large (usually 130 mm or more), and the spindle box has chucks before and after, in order to facilitate the clamping and processing of large-diameter pipes and rods.
Precision ground and supersonic frequency hardened bed ways is designed in double wall structure, giving super rigidity, the spindle is high rigidity and accuracy, the design of the main drive is optimized and the gears in the headstock are precision ground, the noise of the machine is low.
This series of lathe has high power, strong rigidity and wide range of spindle speed adjustment. It is suitable for powerful or high-speed cutting. It can turn end face, outer circle, inner hole, metric, British, module, diametral pitch and other threads, and can undertake drilling, nesting, boring and other processes.
