The surface of the bed ways is supersonic frequency hardened.
Gears precisely ground to reduce noise.
Spindle system is of high rigidity and precision.
Rapid feed structure is available on apron.
One-piece structure casting base.
3-jaw chuck; 4-jaw chuck; steady rest; follow rest; face plate; coolant system; brake system; chasing dial indicator; reduction sleeve; dead centers; full length splash guard; tool and tool box; english manual;
Taper turning attachment; live centers; work light; lead screw guard; digital readout; quick change tool post; chuck guard;
|Height of center||255mm||280mm|
|Swing over bed||510mm||560mm|
|Swing over gap||740mm||790mm|
|Swing over cross slide||310mm||356mm|
|Distance between centers||1000/1500/2000/3000mm|
|Width of bed||350mm|
|Travel of cross slide||320mm|
|Travel of top slide||135mm|
|Spindle internal taper||MT7|
|Range of spindle speeds||25-1600 rpm|
|Metric threads range||0.2-14mm|
|Inch threads range||2-112T.P.I|
|Longitudinal feeds||0.059-1.646 mm/u|
|Cross feeds mm/u||0.02-0.573 mm/u|
|M.P threads range||0.1-7m|
|D.P threads range||4-112 D.P.|
|Tailstock quill diameter||75mm|
|Tailstock quill travel||180mm|
|Taper of tailstock quill||MT5|
|Main motor||7.5 KW|
High precision Gap Bed Lathe Machine C6241/C6246
Precision ground and supersonic frequency hardened bed ways is designed in double wall structure, giving super rigidity, the spindle is high rigidity and accuracy, the design of the main drive is optimized and the gears in the headstock are precision ground, the noise of the machine is low.
This series of lathe has high power, strong rigidity and wide range of spindle speed adjustment. It is suitable for powerful or high-speed cutting. It can turn end face, outer circle, inner hole, metric, British, module, diametral pitch and other threads, and can undertake drilling, nesting, boring and other processes.
QK13 Series CNC Pipe Threading Lathe Machine
CNC pipe thread lathe is a special machine tool for pipe thread turning machining. Its feature is that the spindle bore is relatively large (usually 130 mm or more), and the spindle box has chucks before and after, in order to facilitate the clamping and processing of large-diameter pipes and rods.
