Hydraulic Press Brake WC67Y-80/3200

Hydraulic Press Brake WC67Y-80/3200

Machine introduction:

The Hydraulic Press Brake uses the mold (general or special mold) to bend a cold metal sheet into a workpiece of various geometric cross-section shapes. It is a sheet metal forming machine designed for cold rolling sheet metal processing. It is widely used in sheet metal bending, such as automobile, aircraft manufacturing, light industry, shipbuilding, container, elevator, railway vehicles and other industries.

Share:

Product Description

1. High bending precision, fast working speed, and efficient, operational safety, performance stably.

2. Good antiknock frame(welded-steel plate construction), whole frame is been tempering, reduce modification, using large-scale CNC milling machine, process in one time, insure high-precision.

3. Using international brand parts and cnc.

4. Visual operating system, easy operation, convenient, multi-functions and practical.

5. All parts of cnc hydraulic press brake are produced by cnc produce center, according to standard drawing.

6. High executive force, high standard and high professional machine assembled team.

7. Power safeguard design, with light curtain protection, open door power-off function, more safety when operating.

8. Fashion outlook, delicate, and beautiful, machines are compact design, small floor space, easy operation.

9. Providing comprehensive bending program for all press brake, shearing machine user.

10. Replaceable worktable and the upper and lower mound, no welding, forging and precision grinding.

11. Thickening the slider and the vertical plate, to ensure the stability of the machine tool and reduce the elasticity.

12. Rational layout of the oil pipeline design, to prevent the oil temperature rise quickly.

13. The similarity of images and shipping machine can reach 99.5%.

14. In time fast delivery.

Products Specification

Model No.NormalPressure(KN)Length Of table(mm)DistanceBetween Housing(mm)Stroke(mm)Throat Depth (mm)Motor Power(Kw)
WC67Y/K-40/2000400200015901002005.5
WC67Y/K-40/2200400220015901002005.5
WC67Y/K-40/2500400250020901002005.5
WC67Y/K-50/2500500250019011202505.5
WC67Y/K-50/3200500320026001202505.5
WC67Y/K-63/2500630250020501002505.5
WC67Y/K-63/3200630320026001002505.5
WC67Y/K-80/3200800320026001203207.5
WC67Y/K-80/4000800400032001203207.5
WC67Y/K-100/25001000250019001203207.5
WC67Y/K-100/32001000320026001203207.5
WC67Y/K-100/40001000400032001203207.5
WC67Y/K-100/50001000500040001203207.5
WC67Y/K-125/25001250250020501203207.5
WC67Y/K-125/32001250320026001203207.5
WC67Y/K-125/40001250400032001203207.5
WC67Y/K-125/50001250500040001203207.5
WC67Y/K-160/320016003200260020032011
WC67Y/K-160/400016004000320020032011
WC67Y/K-160/500016005000400020032011
WC67Y/K-160/600016006000490020032011
WC67Y/K-200/320020003200260020032015
WC67Y/K-200/400020004000320020032015
WC67Y/K-200/500020005000400020032015
WC67Y/K-200/600020006000480020032015
WC67Y/K-250/320025003200260020040018.5
WC67Y/K-250/400025004000320025040018.5
WC67Y/K-250/500025005000400025040018.5
WC67Y/K-250/600025006000480025040018.5
WC67Y/K-300/320030003200260025040022
WC67Y/K-300/400030004000320025040022
WC67Y/K-300/500030005000400025040022
WC67Y/K-300/600030006000480025040022
WC67Y/K-400/400040004000320032040022
WC67Y/K-400/500040005000400032040022
WC67Y/K-400/600040006000480032040022
WC67Y/K-500/600050006000480032040037
WC67Y/K-600/700060007000560032040037
WC67Y/K-700/700070007000560032040045
WC67Y/K-800/600080006000480040050055
WC67Y/K-1000/6000100006000480040060075
