Dec. 17, 2021
Customized Hydraulic Shearing Machine QC11Y-6X3200 E21S
The machine can be customized according to the client’s requirements,here we also list some information about this series machine,please kindly check.
* The second generation of hydraulic shear.
* Welded Steel plate structure, heating to eliminate stress, with high strength and good rigidity.
* Advanced integrated hydraulic system with an excellent reliability.
* The rolling guide with 3-point support and improves the shearing quality.
* Rapidly, accurately and conveniently adjusting the blade clearance with the hand wheel.
* The rectangular block blades featuring long lifetime with 4cutting edges in several sections.
* The adjustable rake angle can minimize plate deformation.
* As the cutting beam has been designed in inner- inclined structure, it is easy for plates to fall downand the accuracy of products can be also guaranteed.
* Counter for the motorized back gauge and front control post.
* Rear plate-support of the machine (optional).
* Main electric components are from SIEMENS or Schneider
* Imported hydraulic O-Rings Seals
* Hydraulic gear pump
* Quality hydraulic valves
* CE standard back safety-guard curtain (optional).
Type | Cutting Thickness (mm) | Cutting Width (mm) | Stroke Number (/min) | Travel of Back gauge (mm) | Shearing Angle (0) | Depth of Throat (mm) | Power of Main motor (kw) | Overall Dimensions (mm) |
4x2000 | 4 | 2000 | 14 | 350 | 0.5-1.5 | 80 | 4 | 2600x1350x1840 |
4x2500 | 4 | 2500 | 14 | 350 | 0.5-1.5 | 80 | 4 | 3100x1350x1845 |
6x2500 | 6 | 2500 | 14 | 600 | 0.5-1.5 | 80 | 7.5 | 3100x1725x1960 |
6x3200 | 6 | 3200 | 12 | 600 | 0.5-1.5 | 80 | 7.5 | 3650x1750x1980 |
6x4000 | 6 | 4000 | 10 | 600 | 0.5-1.5 | 80 | 7.5 | 4650x1780x2075 |
6x5000 | 6 | 5000 | 8 | 600 | 0.5-1.5 | 80 | 7.5 | 5650x1830x2250 |
6x6000 | 6 | 6000 | 8 | 600 | 0.5-1.5 | 80 | 7.5 | 6650x189-x2380 |
8x2500 | 8 | 2500 | 14 | 600 | 0.5-1.5 | 80 | 7.5 | 3100x1725x1960 |
8x3200 | 8 | 3200 | 12 | 600 | 0.5-1.5 | 80 | 7.5 | 3850x1750x1980 |
8x4000 | 8 | 4000 | 10 | 600 | 0.5-1.5 | 80 | 7.5 | 4650x1850x2075 |
8x5000 | 8 | 5000 | 7 | 600 | 0.5-1.5 | 80 | 15 | 5805x2000x2500 |
8x6000 | 8 | 6000 | 7 | 600 | 0.5-1.5 | 100 | 15 | 6805x2115x2715 |
10x2500 | 10 | 2500 | 10 | 600 | 0.5-1.5 | 120 | 15 | 3195x1800x2210 |
10x3200 | 10 | 3200 | 8 | 600 | 0.5-1.5 | 120 | 15 | 3895x1800x2240 |
10x4000 | 10 | 40000 | 6 | 600 | 0.5-1.5 | 120 | 15 | 4695x1930x2275 |
10x5000 | 10 | 5000 | 5 | 600 | 0.5-1.5 | 120 | 15 | 5905x2115x2715 |
10x6000 | 10 | 6000 | 5 | 600 | 0.5-1.5 | 120 | 15 | 6905x2215x2800 |
12x2000 | 12 | 2000 | 10 | 600 | 0.5-2.0 | 120 | 15 | 2695x1800x2210 |
12x2500 | 12 | 2500 | 10 | 600 | 0.5-2.0 | 120 | 15 | 3195x1800x2210 |
12x3200 | 12 | 3200 | 8 | 600 | 0.5-2.0 | 120 | 15 | 3895x1800x2240 |
12x4000 | 12 | 4000 | 6 | 600 | 0.5-2.0 | 120 | 15 | 4710x1950x2485 |
12x5000 | 12 | 5000 | 5 | 600 | 0.5-2.0 | 120 | 18.5 | 5905x2115x2800 |
12x6000 | 12 | 6000 | 4 | 600 | 0.5-2.0 | 120 | 18.5 | 7000x2300x3100 |
12x6000 | 12 | 6200 | 4 | 600 | 0.5-2.0 | 120 | 18.5 | 7200x2300x3100 |
16x2500 | 16 | 2500 | 8 | 600 | 0.5-2.5 | 120 | 15 | 3215x1880x2340 |
16x3200 | 16 | 3200 | 7 | 600 | 0.5-2.5 | 120 | 15 | 3915x1880x2445 |
16x4000 | 16 | 4000 | 6 | 600 | 0.5-2.5 | 120 | 15 | 4715x1950x2590 |
16x5000 | 16 | 5000 | 5 | 600 | 0.5-3.0 | 120 | 22 | 6000x23003000 |
16x6000 | 16 | 6000 | 4 | 600 | 0.5-3.0 | 120 | 30 | 7000x2300x3100 |
20x2500 | 20 | 2500 | 6 | 600 | 0.5-3.0 | 120 | 22 | 3215x1890x2465 |
20x3200 | 20 | 3200 | 5 | 600 | 0.5-3.0 | 120 | 30 | 4120x1890x2780 |
20x4000 | 20 | 4000 | 4 | 600 | 0.5-3.0 | 120 | 30 | 4925x2150x2900 |
20x5000 | 20 | 5000 | 4 | 600 | 0.5-3.0 | 120 | 37 | 6000x2300x3050 |
Please contact HAVEN to get the quote, we'll be happy to help you.
