Haven Delivers Custom Pipe Forming Machines to Client

Dec. 19, 2024

Content:

Haven, a trusted name in precision metalworking machinery, has successfully completed a customized set of machines tailored to meet a client's specific production requirements. This comprehensive solution includes a hydraulic pipe bending machine, a pipe chamfering machine, and a taper shrinking machine—each engineered to deliver precise, repeatable results for complex tube and pipe forming tasks.

These machines are now fully assembled, tested, and ready for delivery. Haven continues to demonstrate its dedication to offering tailored solutions that align perfectly with the specialized manufacturing needs of its global customers.



Project Overview: Custom Solutions for Advanced Tube Forming

The client approached Haven with a need for integrated machinery to process a wide range of pipe diameters, wall thicknesses, and end-forming configurations. Rather than offering off-the-shelf machines, the engineering team at Haven worked closely with the client to design and manufacture a matching set of custom-built systems that could perform critical tube forming tasks with high precision and productivity.

The delivered solution includes:

  1. Hydraulic Pipe Bending Machine – for precision tube forming

  2. Pipe Chamfering Machine – for clean, burr-free edge preparation

  3. Taper Shrinking Machine – for diameter reduction and end-shaping

These systems are commonly applied in industries such as automotive exhaust production, structural steelworks, HVAC ducting, and pipeline infrastructure.


chamfering machine (1).jpg

chamfering machine (2).jpg

1. Hydraulic Pipe Bending Machine

This machine is at the core of the forming line. Equipped with high-tonnage hydraulic cylinders, this pipe bending system offers stable, powerful forming across a variety of pipe sizes and bending radii. The machine allows for programmable angles and multiple bend configurations—perfect for complex geometries and batch consistency.

Thanks to Haven’s robust mechanical design and industrial-grade hydraulic systems, this pipe bender is both durable and accurate, capable of handling heavy wall or high-strength steel tubing. The system includes intuitive controls for angle programming and positioning, improving both operator efficiency and setup speed.

This machine is categorized under Hydraulic Press Brake class, due to similar hydraulic forming principles and structural build.


2. Pipe Chamfering Machine

The pipe chamfering unit provides clean, consistent edge preparation—an essential step before welding or joining. This machine supports multiple chamfer angles and pipe sizes, ensuring that both inner and outer pipe edges are processed to precise tolerances. The result is a smooth and burr-free finish, reducing risk of weld defects and assembly misfits.

The machine is equipped with adjustable clamping and feed mechanisms, enabling high-volume production without compromising on quality.


3. Taper Shrinking Machine

For applications where one end of a pipe needs to be narrowed or reshaped, the taper shrinking machine delivers precision forming with minimal distortion. This is particularly useful in telescopic tubing, exhaust assemblies, or tight-fit connections in hydraulic and pneumatic systems.

The shrinking process is hydraulic-driven, offering consistent force distribution across the pipe circumference. The toolsets are fully customizable, ensuring compatibility with various taper lengths, angles, and wall thicknesses.

Customization Based on Client Requirements

Each of the machines was built based on the client’s production layout, part specifications, and workflow preferences. This included:

  • Special clamping systems for non-standard pipe profiles

  • Custom machine color and branding

  • Integration-ready electrical controls with PLC interface

  • Foot pedal and safety light curtain options for improved safety

  • Custom feed height to match existing conveyor lines

Haven’s engineering team worked closely with the client throughout the design, manufacturing, and testing phases to ensure that the final equipment met every functional and quality expectation.

hydraulic pipe bending machine  (3).jpg

hydraulic pipe bending machine  (2).jpg

hydraulic pipe bending machine  (1).jpg

Haven’s Commitment to Tailored Machinery

At Haven, customization is more than a service—it's a core philosophy. Many clients operate in niche sectors where standard machines don’t deliver optimal performance. That’s why Haven offers flexible engineering, rapid prototyping, and detailed technical support for any custom machinery project.

Whether the requirement is special forming forces, non-standard part geometries, or automation-ready equipment, Haven brings decades of expertise to build the right solution.

To explore more about Haven’s wide range of machinery, visit the official website.


Contact Haven for Custom Machine Solutions

If your manufacturing operation requires specialized machines for forming, cutting, bending, or shaping, Haven is ready to deliver. With clients across Asia, Europe, the Middle East, and the Americas, Haven continues to lead with engineering precision, reliability, and customer focus.

Contact Haven today to request a quote, share your design parameters, or consult with an application engineer.

Taper shrinking machine (2).jpgTaper shrinking machine (1).jpg


About Haven

Haven is a leading Chinese manufacturer of high-performance metalworking equipment, offering complete solutions in CNC lathes, fiber laser cutting, hydraulic press brakes, shears, and customized production lines. With a commitment to innovation, precision, and customer satisfaction, Haven helps industries worldwide improve their manufacturing capabilities.
